elektraLite ElektraBar Vibe - NEW

The Vibe sports 128 columns of seven RGBW LEDs for a total of 896 “pixels” each providing 0.3 watts for a combined 268.8 watts of emitter output. Boasting a generous beam spread of 120 degrees, multiple elektraBar Vibes can be linked together via side-panel locking plates to create a near seamless line of brilliant visuals for the stage.

A truly versatile performer, the Vibe is flicker-free and can be used in a variety of ways for illuminating a stage: as a cyc light, or for side, back, or front lighting. If the 120-degree beam spread is too wide, its width can be cut with an available glare shield for beam control and rough focusing. The product can also be aimed at the audience and used as a light source to project pixel-mapping LEDs, which can be combined into a larger composite image when multiple Vibes are deployed together.

Housed in a robust gloss gray aluminum chassis equipped with corrosion-resistant hardware and a rigid flat steel yoke, the Vibe can be mounted from either a single handle point in the center or from its included trunnion feet.

Features:

• LED technology; utilizing 896 0.3‐watt LEDs
• Individual cell control per 2 rows of 7 (14 LEDs total)
• Controllable in 13-channel, 256-channel, or 258-channel modes
• Versatile for use in a variety of applications
• Can be linked together via side-panel locking plates

Specifications:

• Power Consumption: 375 watts (3.0A)
• Electrical: Multi-voltage; AC 100-240V – 50/60Hz
• Housing: Gloss gray aluminum
• Materials: Corrosion-resistant hardware
• Yoke: Rigid flat steel
• Light Engine: 896 0.3 watt LED emitters
• Beam Spread: 120 degrees
• Refresh Rate: >800Hz
• CRI: 95
• Optics / Lensing(s): Frosted lens
• Control: DMX 5-pin and ArtNet (CAT 5)
• Dimming: 16 bit, DMX controlled
• Physical Dimensions: L 39″ W 6″ H 5″
• Weight: 11.5 lbs / 5.2 Kgs
